TOSHIBA 60V N-Channel High Voltage Power Mosfet for White LED Strings

Toshiba America Electronic Components, Inc., (TAEC)* is now offering a 60 volt power MOSFET driver for white light emitting diodes (LEDs) primarily targeted for LCD panel backlight applications such as car navigation monitors and 12-inch notebook PCs. These applications typically require high voltage of 24V to 48V to activate 8 to 16 white LEDs in series.

The Toshiba SSM3K318T n-channel power MOSFET is small in size and well suited to boost a battery voltage to the level needed to turn on the LED array, with both high speed switching and low ON-resistance (RDS(ON)) for higher efficiency.

The SSM3K318T features low ON-resistance of 83.5 milliohms (typ.) at VGS = 10V, and low capacitance of 235 pF at VDS = 30V. The new device is available in a compact TSM package that measures 2.9mm x 2.8mm x 0.7mm.

"The low RDS(ON) and capacitance of these devices increase efficiency and translate into longer battery life for mobile applications using white LEDs as backlights for the display," said Talayeh Saderi, business development engineer, RF and small signal devices, for TAEC.

Toshiba's broad selection of low ON-resistance small signal MOSFETs (S-MOS) is suitable for high-speed switching devices in portable electronics equipment. The MOSFETs feature among the lowest ON-resistance and lowest capacitance in the industry and are designed to save space while meeting designers' requirements. For more information, please visit http://www.toshiba.com/taec/adinfo/small-signal/

Pricing and Availability:
The Toshiba SSM3K318T white LED driver is available now, with prices in OEM quantities beginning at $0.65/each.

Toshiba’s Discrete Products:
Since 1986, Toshiba Corp. has ranked as the top discrete supplier on a worldwide basis, based on annual revenue from international shipments of total discrete products. According to the most recent annual report from market research firm Gartner Dataquest (San Jose, CA), Toshiba remained the top discrete semiconductor supplier. (Source: “2008 Worldwide Semiconductor Market Share Report,” Gartner released, April 2009). More specifically, Toshiba is a leading supplier in a number of discrete product categories, including power transistors, rectifiers and thyristors, LMOS logic, CMOS logic, photocouplers, Toslinks™, LEDs, small signal diodes and transistors. The company’s discrete devices are designed to meet the growing demand for high-performance and lower voltages in today’s wireless telecommunications and consumer electronics applications, while emphasizing its strength in the automotive and industrial markets.

About TAEC and Toshiba Corp.:
Through proven commitment, lasting relationships and advanced, reliable electronic components, Toshiba enables its customers to create market-leading designs. Toshiba is the heartbeat within product breakthroughs from OEMs, ODMs, CMs, distributions and fabless chip companies worldwide. A committed electronic components leader, Toshiba designs and manufactures high-quality flash memory-based storage solutions, discrete devices, displays, advanced materials, medical tubes, custom SoCs/ASICs, digital multimedia and imaging products, microcontrollers and wireless components that make possible today’s leading cell phones, MP3 players, cameras, medical devices, automotive electronics and more.

Toshiba America Electronic Components, Inc. is an independent operating company owned by Toshiba America, Inc., a subsidiary of Toshiba Corporation, Japan’s largest semiconductor manufacturer and the world’s third largest semiconductor manufacturer (Gartner, 2008 WW Semiconductor Revenue, April 2009). For additional company and product information, please visit http://www.toshiba.com/taec/ .
