LUXEON Q: Industry Standard 3535 Footprint Delivering Market Leading High Flux

LUXEON Q delivers superior performance in a high-power emitter that serves as a direct drop-in replacement for products that use the standard 3535 surface mount package. LUXEON Q is the first high-power LED based on LUXEON Flip Chip die, Philips Lumileds high performance Chip Scale Package (CSP) device architecture.

Efficacy for the LUXEON Q emitter is 135 lm/W at 5700K 70 CRI and 115 lm/W at 3000K 80 CRI (@85˚C and 350 mA).  The LED is especially competitive when it’s driven harder. For instance, at 1 amp, a flux of more than 300 lm at an efficacy of 102 lm/W at 85˚C is achieved in neutral white at 4000K. The high efficacy at high drive current of the LUXEON Q emitter is achieved as a result of the industry leading wall plug and conversion efficiency of Philips Lumileds next-generation CSP architecture.

The LUXEON Q emitter line is available in CCTs of 2700K, 3000K, and 3500K at 80 CRI and CCTs of 4000K and 5700K at 70 CRI.

For more information on LUXEON Q, please visit: www.philipslumileds.com/LUXEONQ
