Automotive | LEDs | Components | Jun 21, 2016

Samsung Introduces New Line-Up of CSP LEDs for Automotive Lighting

Samsung Electronics Co., Ltd., a world leader in advanced component solutions, announced today that it has introduced “Fx-CSP”, a line-up of LED packages which features chip-scale packaging* and flexible circuit board technology, for use in automotive lighting applications.

“Our new Fx-CSP line-up will bring greater design flexibility and cost competitiveness to the automotive lighting industry,” said Jacob Tarn, executive vice president, LED Business Team, Samsung Electronics. He added that, “We will continue to introduce innovative LED products and technologies, such as multi-chip array technology, that can play a key role in the growth of the automotive LED lighting industry.”

Samsung’s new Fx-CSP provides an advanced combination of chip-scale packaging and flexible circuit board technology, which together enable more compact chip sizing and a higher degree of reliability. The use of a flexible circuit board also enables more heat to dissipate, which leads to lower resistance and brings about a greater degree of lumen-per-watt efficiency than using a ceramic board.

In addition, the new Samsung automotive LED line-up allows car designers to use a variety of chip arrangements such as a single chip, a 1 by 4, or a 2 by 6 multi-chip arrangement to suit different lighting configurations. The Fx-CSP line-up can be widely used in automotive lighting applications that include position lamps** and daytime** running lamps as well as headlamps** that require higher luminous flux and reliability than other automotive lamps.

The Fx-CSP line-up consists of single packages, Fx1M and Fx1L, with 1-3 watts each, as well as packages with a 14 W high voltage array, Fx4 and a 40 W high voltage array, Fx2x6. The variation in wattage levels allows Samsung LED lighting packages to work well with a wide range of exterior automotive lighting.

By adding the new Fx-CSP line-up to its existing mid-power and high-power automotive LED component line-ups, Samsung now provides a highly competitive family of automotive lighting components.

Fx-CSP Product Line-UP:

Product     Chip
arrangement
Power
consumption
(W)
Application

Fx1M           1x1         1        Daytime running lamp,
Position lamp
Fx1L           1x1         3 Daytime running lamp
Fx4       1x4        14     Headlamp, Light guide type daytime running lamp
Fx2x6          2x6        40    Multi-beam headlamp

Samsung’s new Fx-CSP LED line-up was recently selected for a compact car headlamp project from one of the major global automotive manufacturers.

Samsung plans to introduce more CSP technology-based LED components such as the new Fx-CSP line-up for automotive lighting, later this year.

About Samsung Electronics Co., Ltd:

Samsung Electronics Co., Ltd. inspires the world and shapes the future with transformative ideas and technologies. The company is redefining the worlds of TVs, smartphones, wearable devices, tablets, cameras, digital appliances, printers, medical equipment, network systems, and semiconductor and LED solutions. For the latest news, please visit the Samsung Newsroom at news.samsung.com
