Products, Materials + Tools | Sep 17, 2012

AEM Intros SMD Electronic Fuse Family for LED Lighting Overcurrent Protection

AEM Components™ today introduced its new AirMatrix® 2410 family of surface mount electronic fuses that provide AC line overcurrent protection for LED lighting applications. AirMatrix is provided in an EIA 2410 compact package. LED light bulb assemblies have limited board space making the AirMatrix package size ideal for this and other space constrained applications. The AirMatrix 2410 package enables flexible board placement and is compatible with standard pick-and-place technology. This also reduces assembly cost and saves board space.

AEM's AirMatrix 2410 is the industry's smallest fuse body with 250VAC rating. AirMatrix has an operating temperature range of -55 degrees Celsius to 125 degrees Celsius. The series complies with multiple safety standards including UL, PSE, TUV and CQC.

The AirMatrix surface mount devices (SMD) are lead-free, halogen-free and RoHS complaint. AirMatrix electronic fuses are offered in a wide range of current ratings for various applications: 0.5 A – 2 A (250 VAC / 125 VDC), 2.5 A – 10 A (125 VAC / 125 VDC) and 12 A – 20 A (65 VAC / 65 VDC).  They are also suitable for other common AC and DC applications. They include LCD TVs; telecommunications and networking equipment; battery packs; server and storage systems; power adapters; backlight drivers; industrial and medical equipment; and more.

Pricing and Availability:
Pricing for AirMatrix fuses start at $0.26 for quantities of 2,000. The AirMatrix data sheet is available online. An application note is available here. Interested parties can also contact a local AEM distributor near their area.

About AEM Components:
With more than 20 years' industry experience, AEM Components (USA), Inc. is a leading provider of circuit protection components. AEM's surface mount fuses, ESD suppressors, and multilayer varistors (MLV) are deployed globally for circuit protection and ESD protection. AEM's AirMatrix® surface mount device (SMD) fuses are capable of sustaining high interrupting ratings for overcurrent protection. The company's SolidMatrix® SMD fuses provide secondary circuit protection in DC power applications. AEM's GcDiode® ESD suppressors provide reliable ESD protection for high speed data ports. AEM's MLVs are available for low energy ESD protection or high energy voltage surge protection. The company also offers chip inductors and beads for electromagnetic (EMI) signal filtering. AEM maintains research and development centers, manufacturing facilities and sales offices in the USA and throughout Asia. More information is available at www.aemcomponents.com.
