Cypress Introduced New PowerPSoC® Family

Cypress Semiconductor Corp. (NYSE: CY) today introduced the PowerPSoC® family of integrated embedded power controllers, the industry’s first single-chip solution for both controlling and driving high-power LEDs.

The PowerPSoC family integrates four constant-current regulators and four 32V MOSFETs with Cypress’s PSoC® programmable system-on-chip, which includes a microcontroller, programmable analog and digital blocks, and memory.

This unprecedented level of integration provides customers with a single-chip solution for high-quality LED-based lighting products, and extends into other embedded applications such as white goods and industrial control. The result is end systems with fewer components, faster design cycles, lower power consumption and higher reliability. More information on the PowerPSoC family is available at www.cypress.com/go/pr/PowerPSoC.
The companion software for PowerPSoC, the PSoC Designer™ development tool, enables designers to quickly and efficiently program the controllers for different lighting and power options. It also allows changes late in the design cycle without having to change the circuit board layout.   “We are bringing the unique PSoC value propositions—integration, flexibility and programmable analog—to a new set of applications and customers,” said Curtis Davis, vice president of Cypress’s PowerPSoC Division. “PowerPSoC represents an important step in the development of the PSoC platform, as well as the entire Cypress product line.”   “General illumination, medical, and architectural LED lighting applications all stand to benefit from the combination of integration and programmability offered by PowerPSoC,” stated Jeff Shepard, President of Darnell Group, Inc. “Those same applications offer long-term compound growth for the next five years of over 90%/year, as well as immediate growth potential in 2009.”   PowerPSoC Features Integrated Power Peripherals
  • Up to four integrated, independently operated 32V / 1A MOSFETs offer the ability to drive high power LEDs up to 1A.
  • Up to four programmable hysteretic controllers provide controlled current output.
  • Up to four low-side gate drivers with programmable drive strength provide the ability to support voltages above 32V with external MOSFETs
  • Up to 2MHz switching frequency allows smaller, less expensive inductors.
  • Floating load buck, floating load buck-boost, and boost converter topologies enable flexibility for applications’ different voltage requirements.
  • Auxiliary power regulator offers the ability to power the chip from a single power supply.
  • 16-bit dimming for lighting applications that require high-resolution dimming
PSoC Architecture
  • Eight programmable digital blocks for functions such as timers, counters, PWMs, and UARTs.
  • Six programmable analog blocks for functions such as amplifiers, ADCs, DACs, filters and comparators.
  • 16K of Flash memory
  • 8-bit microcontroller
Availability The following PowerPSoC devices are available today:

Part Number

Number of Channels

Internal FETs

Package

CY8CLED04D01-56LTXI

4

4 x 1A

56-pin QFN

CY8CLED04D02-56LTXI

4

4x 0.5A

56-pin QFN

CY8CLED04G01-56LTXI

4

N/A

56-pin QFN

CY8CLED03D01-56LTXI

3

3 x 1A

56-pin QFN

CY8CLED03D02-56LTXI

3

3 x 0.5A

56-pin QFN

CY8CLED03G01-56LTXI

3

N/A

56-pin QFN



In addition, Cypress is offering the CY3268 demonstration kit, which drives four LEDs in a small form-factor (2.5” x 3.5’’) with basic reprogramming/debugging capability. A PowerPSoC evaluation kit (CY3267) is also available for customer prototyping. It offers a modular approach with interface for daughter-cards to support multiple applications, multiple protocols (DMX512 and DALI) and customer-specific daughter cards. The CY3267 also offers flexible topology, supporting buck, boost and buck-boost configurations. Both of the PowerPSoC kits are available today from www.cypress.com.The CY3268 is priced at US$60 and the CY3267 is priced at US$175.



About Cypress’s Intelligent Lighting Solutions

LED lighting design requires a complex set of calculations with custom firmware to deliver consistent color. The two biggest problems that LED lighting engineers face are having to account for differing LED performance specifications based on manufacturing bins and the LEDs’ degradation (such as output flux, wavelength etc.) over different temperatures. With PSoC Designer, designers simply select a color from a gamut presented on-screen. Cypress offers temperature or optical feedback algorithms that are automatically applied to the selected design and programmed into a Cypress controller. This can save anywhere from weeks to months of design time for a complex design.



PSoC—Because Change Happens

PSoC devices employ a highly configurable system-on-chip architecture for embedded control design, offering a flash-based equivalent of a field-programmable ASIC without lead-time or NRE penalties. PSoC devices integrate configurable analog and digital circuits, controlled by an on-chip microcontroller, providing both enhanced design revision capability and component count savings. They include up to 32 Kbytes of Flash memory, 2 Kbytes of SRAM, an 8x8 multiplier with 32-bit accumulator, power and sleep monitoring circuits, and hardware I2C communications.



A single PSoC device can integrate as many as 100 peripheral functions saving customers design time, board space and power consumption while improving system quality and reducing system cost.

The flexible PSoC resources allow designers to future-proof their products by enabling firmware-based changes during design, validation, production, and in the field. The unique PSoC flexibility shortens design cycle time and allows for late-breaking feature enhancements. All PSoC devices are also dynamically reconfigurable, enabling designers to morph internal resources on-the-fly, utilizing fewer components to perform a given task. More information about PSoC products is available at www.cypress.com/psoc and free online training is at www.cypress.com/psoctraining.



About Cypress

Cypress delivers high-performance, mixed-signal, programmable solutions that provide customers with rapid time-to-market and exceptional system value. Cypress offerings include the PSoC® programmable system-on-chip, USB controllers, general-purpose programmable clocks and memories. Cypress also offers wired and wireless connectivity technologies ranging from its CyFi™ Low-Power RF solution, to West Bridge® and EZ-USB® FX2LP controllers that enhance connectivity and performance in multimedia handsets. Cypress serves numerous markets including consumer, computation, data communications, automotive, and industrial. Cypress trades on the NYSE under the ticker symbol CY. Visit Cypress online at www.cypress.com.

# # #



Cypress, the Cypress logo, PowerPSoC, PSoC, West Bridge and EZ-USB are registered trademarks, and, EZ-Color, PrISM, PSoC Designer and CyFi are trademarks of Cypress Semiconductor Corporation. All other trademarks are the property of their respective owners.
