Products, Materials & Tools | May 09, 2012

Microsemi Unveils Ultra-fast-startup LED Driver for Linear Lighting Fixtures

Microsemi Corporation, a leading provider of semiconductor solutions differentiated by power, security, reliability and performance, today unveiled a new dimmable LED driver module optimized for worldwide residential, commercial and industrial light fixtures. The 30 watt (W) LXMG221W-0700030-D0™ LED driver enables start up times of 150 milliseconds (ms) or faster, closely emulating the "lights-on" performance of a typical incandescent lamp. This is important for home and business applications where light start-up delays are unacceptable. Microsemi's new ENERGY STAR-compliant, solid state LED driver provides over voltage and current protection, as well as automatic over-temperature shutdown to facilitate reliable and safe operation.

According to estimates from industry analyst firm Strategies Unlimited, the commercial, industrial and residential LED fixture market approached $3 billion in 2011, excluding lamp replacement fixtures. The total LED fixture market is expected to increase at a compound annual revenue growth rate of approximately 20 percent from 2011 to 2016.

"The adoption of regulations imposing a phase-out of inefficient incandescent lamps is driving the growth of alternative light sources including energy-efficient LEDs globally," stated Irene Signorino, director of business development at Microsemi. "Our new LED driver allows light fixture manufacturers to capitalize on this growing market opportunity. As always, we remain committed to applying our expertise in lighting and power matters to solving challenging industry issues."

Power-efficient LED lights are becoming increasingly popular for use in homes and businesses alike. However, the energy-savings benefits often don't outweigh the instant-lighting performance that people have come to expect from incandescent lights in such applications. Microsemi's new LED driver solves this issue by delivering a 150ms or shorter startup time that is not noticeable by the human eye. This attribute, coupled with the device's form factor and power/current levels, makes it ideal for use in areas where "instant-on" lighting is required or expected.

Microsemi's new LED driver is compatible with 50 Hz and 60 Hz AC power sources worldwide with standard voltages ranging from 120 VAC +/ -10 percent to 277 VAC +/-10 percent. The output is a 700 milliamps (mA) dimmable constant current source. It complies with UL, CUL, CE and EMC industry standards.

Additional features include:
• High-voltage AC input (90-305 VAC) for worldwide installations
• Constant current single 700mA string applications using ~5-12 LEDs without flickering (up to 30W output)
• High power factor (PF > 0.9) and low total harmonic distortion (THD < 15%) across the entire input voltage range at full load to meet or exceed standard requirements
• Dimmable to 10 percent via 0-10VDC (compliant to IEC 60929), PWM controls or potentiometers for additional energy savings
• FCC Title 47, part 15 Class B compliant

Availability and Pricing:

The LXMG221W-0700030-D0 is available in production quantities now. For volume OEM pricing, please contact a Microsemi sales representative via email at A list of sales representatives can be found at

About Microsemi:
Microsemi Corporation (Nasdaq: MSCC) offers a comprehensive portfolio of semiconductor and system solutions for communications, defense and security, aerospace, industrial and medical markets. Products include mixed-signal integrated circuits, SoCs and ASICS; programmable logic solutions; power management products; timing and voice processing devices; RF solutions; discrete components; and Power-over-Ethernet ICs and midspans. Microsemi is headquartered in Aliso Viejo, Calif., and has approximately 3,000 employees globally. Learn more at
