Low Viscosity, Two Component Epoxy is Optically Clear with Non-Yellowing Properties

Master Bond EP112LS is a two part epoxy that is well suited for impregnation, potting, encapsulation, sealing and coating applications, particularly in the aerospace and optoelectronics industries.

EP112LS is optically clear, features reliable non-yellowing properties and has a refractive index of 1.55. This electrically insulative system is resistant to chemicals including water, oils, fuels, acids and bases. EP112LS is serviceable over the temperature range of -60°F to +450°F.

This system features a working life exceeding 2-3 days at room temperature and requires oven curing. Post curing will enhance its properties. With a mixed viscosity of 50-200 cps, EP112LS bonds well to a wide variety of substrates, including metals, composites, glass, ceramics and many rubbers and plastics. Bonds feature a tensile strength, compressive strength and tensile modulus of 11,000 psi, 20,000 psi and 400,000 psi at room temperature, respectively. Dimensional stability is outstanding.

EP112LS has a shelf life of one year in original, unopened containers and is available in ½ pint, pint, quart, gallon and 5 gallon container kits.

Master Bond Electrically Insulative Adhesive Systems
Master Bond 112LS is an optically clear, low viscosity epoxy that has been formulated for a variety of high performance applications. This two component, heat curing system is also a competent electrical insulator, even at elevated temperatures.

Read more about Master Bond’s electrically insulative adhesives at http://www.masterbond.com/properties/electrically-insulative-adhesive-systems or contact Tech Support.
Phone: +1-201-343-8983 Fax: +1-201-343-2132
Email: technical@masterbond.com.

For a full product description, please visit: http://www.masterbond.com/tds/ep112ls

About Masterbond:
Master Bond Inc. was founded in 1976. Our focus has been on developing the best in epoxies, silicones, polyurethanes, polysulfides, UV cures and other specialty adhesive systems. We are true specialists in our field and are recognized by many as the preeminent adhesive formulation company in the world.
Master Bond Inc. formulates the highest quality products and offers unmatched technical advice and customer support. Our product line consists of advanced adhesives, sealants, coatings, potting/encapsulation compounds and impregnation resins. Each compound is designed to meet specific application needs and requirements.
Master Bond manufactures over 3,000 grades of specially designed formulations. We also offer replacements for competitors’ discontinued products.
