Exar Introduces New Programmable High Brightness LED Driver IC

Exar Corporation (Nasdaq: EXAR) a leading supplier of high performance analog mixed-signal components and data management solutions today introduced the XRP7613, a programmable high current, high brightness LED Driver. Capable of driving LED currents up to 1.2A, the XRP7613 operates from input voltages up to 36V and supports analog and Pulse Width Modulation (PWM) dimming up to 40KHz.

Designed for retail and architectural lighting applications, the XRP7613 offers a proprietary and selectable LED thermal current fold-back mode of operation that effectively reduces the programmed LED current as the ambient temperature increases. This feature provides additional reliability for the whole system and longer operation under adverse temperature conditions. The XRP7613 supports a wide range of programmable LED currents, from150mA to 1.2A, making it ideal for various LED brightness and light fixture wattage. Additionally, an extended operating voltage range of up to 36V allows usage of the XRP7613 in industrial lighting applications where power transmission line losses are minimized through higher input voltage rails.

"The XRP7613 offers customers a number of leading features including the thermal current fold-back mode which maintains the LED lit under stressfull temperature conditions where most other drivers would simply turn off," said Eric Pittana, Exar's Power Management marketing director. "Ultimately, the XRP7613 enables an enhanced consumer lighting experience with a longer lasting and more reliable lighting fixture."

Product Details:
The XRP7613 is a non-synchronous step down driver with integrated FET optimized to drive high power LEDs up to 1.2A while supporting up to 36V on the input. The XRP7613 has a switching frequency of up to 1MHz, a programmable output current from 150mA to 1.2A, and supports both analog as well as PWM dimming up to 40KHz. A selectable LED thermal current fold-back control feature linearly reduces the LED current as temperature rises to ensure continuous lighting. The XRP7613 also provides designers with a compact and robust LED driver solution capable of fitting into the popular MR16 space constraint sockets.

Applications:
• General Lighting and Displays
• Architectural and Accent Lighting
• Medical and Industrial Instrumentation
• Video Projectors

Features:
• 1.2 A Continuous Output LED Current ◦150 mA to 1.2 A Programmable Range
• 7 V to 36 V Single Rail Input Voltage
• PWM & Analog Dimming Capability ◦Up to 40 kHz Frequency
• LED Current Foldback Thermal Control ◦Selectable Automatic Linear Dimming of LED Current with temperature
• Shutdown Control
• Built-in Soft Start
• Open LED, LED Short Circuit and Over Temperature Protections
• RoHS Compliant "Green"/Halogen Free 8-pin Exposed Pad SOIC Package

Product Availability and Pricing:
The XRP7613 is available now in volume quantities and comes standard in a RoHS compliant, Halogen Free 8-Pin Exposed Pad SOIC package. The 1,000-unit suggested retail is $0.99 each. Exar also offers an evaluation board for customers to quickly and easily test the features of the XRP7613.
