NXP Brings High Efficiency to 12V MR16 Lamps with Dimmable LED Controller

NXP Semiconductors N.V. today unveiled the SSL3401 – a dimmable single-stage controller IC for retrofit MR16 LED lamps using 12V AC mains. The SSL3401 offers compatibility with an exceptionally wide range of dimmers and transformers – working with over 80% of the most common combinations – in a compact form factor that fits in all commonly used MR16 GU5.3 and AR111 housings and sockets. Supporting an ambient temperature range up to 105ºC, the SSL3401 also provides temperature rollback protection.

Features and benefits:
•    Easy migration to existing lighting control infrastructure
•    Support most available dimmers and low voltage transformation solutions
•    Excellent stability of LED current
•    Double PI controllers to enhance the line regulation of the LED current
•    Optimized dimming curve for low voltage transformer compatibility
•    Automatic supply frequency detection for seamless operation with 50 Hz, 60 Hz or DC sources
•    Dimmer conduction angle detection
•    Coil current limitation
•    Temperature roll-back protection
•    OverVoltage Protection (OVP)
•    Power-On-Reset (POR)
•    Shorted LED protection
•    Open LED detection
•    UnderVoltage LockOut (UVLO)

Applications:
•    General LED lighting with various power requirements
•    Dimmable 12 V MR16 and AR111 applications

Based on NXP GreenChip™ technology, the SSL3401 generates a stable and accurate current while dimming down to below 5% of maximum light output in most common practical situations. While maximum lamp power depends on the thermal design of the lamp, a typical 7W MR16 LED lamp using the SSL3401 achieves THD below 15%, power factor above 0.9, efficiency up to 78% and LED ripple current below ±10%.

“Energy-conscious consumers and businesses worldwide are keen to replace halogen lamps with LEDs – but making the switch to dimmable MR16 LEDs is not always as straightforward as one would expect. With the SSL3401, we’ve designed a compact single-stage controller IC specifically for dimmable MR16 LED lamps, and tested it extensively for compatibility with a wide range of dimmers and transformers,” said Ryan Zahn, general manager, lighting solutions product line, NXP Semiconductors. “By helping retrofit lamp manufacturers to reduce costs, we also hope to ease the transition from halogen to LED on a broader scale, particularly as 12V MR16 lamps emerge as a popular choice in both commercial and residential lighting.”

NXP is showcasing the SSL3401 at Guangzhou International Lighting Exhibition this week (Hall 13.2, Booth D37). Evaluation samples are available now, with volume production starting in July 2013.
For a first more detailed information please visit http://www.nxp.com/pip/SSL3401HN
For information about other SSL driver ICs please visit the NXP Lighting Driver Solutions Selection Guide at http://nxp.com/led or http://nxp.com/ssl

About NXP Semiconductors N.V:
Semiconductors N.V. (NASDAQ: NXPI) provides High Performance Mixed Signal and Standard Product solutions that leverage its leading RF, Analog, Power Management, Interface, Security and Digital Processing expertise. These innovations are used in a wide range of automotive, identification, wireless infrastructure, lighting, industrial, mobile, consumer and computing applications.  A global semiconductor company with operations in more than 25 countries, NXP posted revenue of $4.36 billion in 2012. Additional information can be found by visiting www.nxp.com.
