Nordson ASYMTEK Fluid Dispensers Jet Precisely into Narrow Cavities To Improve Side-View LED Manufacturing Process

Nordson ASYMTEK, a leader in dispensing, coating, and jetting technologies, introduces jet dispensing for manufacturing side-view LEDs. The system jets 0.1 to 0.2 mm dots through windows as small as 0.4 mm into the LED cavities. Side-view LEDs illuminate the displays in devices such as tablet computers, smart phones, and e-readers. Nordson ASYMTEK's Spectrum™ S-920N jetting system automatically maintains a consistent shot weight with software-managed dispense parameters. Closed-loop dispensing eliminates the need for time-consuming operator adjustment. Unlike other multi-headed needle dispensing systems, Nordson ASYMTEK's system is easier to set up and maintain in production, keeping your process under machine control.

"Consistent dispensing weight improves process capability while ensuring higher UPH (units per hour)," said Akira Morita, business development manager at Nordson ASYMTEK. "Using CPJ+ (calibrated process jetting plus), the process variability is reduced for tight LED color quality. This patented, technologically advanced software and hardware control reduces process variation, increases yield, and reduces cost."

The system uses a jet for non-contact dispensing. Unlike a needle, the jet retracts much less for silicone break off and therefore shoots multiple shots faster, increasing speed and throughput. The jet's small, controlled drops of fluid reach tight cavities consistently and reliably, unlike needles which have orifices larger than the cavity windows of side-view LEDs.

"As these LED devices get slimmer, the challenge to dispense specialized fluids, like silicone phosphor, into these tight spaces becomes greater," explained Morita. "Nordson ASYMTEK's dispensing system overcomes these challenges."

About Nordson ASYMTEK:
Nordson ASYMTEK, a world leader in precision automated fluid dispensing, conformal coating, and jetting technologies, designs and manufactures a full line of dispensing and coating systems, supported by a global applications and service network. Recognized for its innovative equipment and excellent service, Nordson ASYMTEK continues to offer advanced dispensing solutions for a range of precision assembly processes. These include semiconductor packaging, printed circuit boards, LEDs, flat panel displays, medical and biotechnical devices, and solar and photovoltaic products. Nordson ASYMTEK is an ISO 9001:2008 certified company and has received numerous awards for its service excellence and product innovations. For more information, visit www.nordsonasymtek.com/, or www.twitter.com/NordsonASYMTEK.

About Nordson Corporation:
Nordson Corporation (Nasdaq: NDSN) is one of the world's leading producers of precision dispensing equipment that applies adhesives, sealants, liquid and powder coatings and other materials to a broad range of consumer and industrial products during manufacturing operations. The company also manufactures equipment used in the testing and inspection of electronic components as well as technology-based systems for UV curing and surface treatment processes. Headquartered in Westlake, Ohio, Nordson has direct operations and sales support offices in more than 30 countries. Visit Nordson at www.nordson.com/, www.twitter.com/Nordson_Corp or Facebook.
