Products, Materials & Tools | Mar 24, 2015

Philips Lumileds Launches LED for Single-Source Beam Control in Directional Lamps

Makers of directional lamps now have a more affordable LED option that offers single-source beam control: the Philips Lumileds LUXEON 5258. This multi-die emitter enables the most cost effective design of PAR 16, PAR 20, MR16 and GU10 lamps using existing drivers at 24V and 96V.

Key Applications:
•    Lamps
--    MR16
--    GU10
•    Spotlights
--    Track heads

Features & Benefits:
•    5mm optical source enables good optic design for great punch
•    Hot-color targeting ensures color is within ANSI bin at 85°C
•    Binned within 3-step and 5-step MacAdam ellipse ensuring color uniformity
•    Compatible with low cost and high efficiency drivers
•    Available in 24V and 96V options

“We are providing a high flux, high efficacy LED that improves the quality of light and avoids the unfortunate “showerhead effect” that users experience with distributed, multi-die solutions. The LUXEON 5258 can achieve lower system costs compared to solutions using multiple LEDs for 35 W and 50 W MR16 today,” said Ahmed Eweida, Product Manager. Lumileds initial offering of the LEDs in the 5258 plastic package is in warm white CCTs with a minimum CRI of 80. The 24 V solutions provide 425 lumens at 110 lm/W, while the 96 V solutions provide 400 lumens at 105 lm/W. However, both can be driven to deliver up to 650 lumens. A 5 mm diameter optical source enables precise beam control in directional applications.

The LUXEON 5258 is designed to provide the best efficacy and flux metrics with superior reliability and droop curve than all competing solutions on the market.

About Philips Lumileds:

Philips Lumileds focuses on one goal: Creating the world’s highest performing LEDs. The company pioneered the use of solid-state lighting in breakthrough products such as the first LED backlit TV, the first LED flash in camera phones, and the first LED daytime running lights for cars. Today we offer the most comprehensive portfolio of high quality LEDs and uncompromising service.
Philips Lumileds brings LED’s qualities of energy efficiency, digital control and long life to spotlights, downlights, high bay and low bay lighting, indoor area lighting, architectural and specialty lighting as well as retrofit lamps. Our products are engineered for optimal light quality and unprecedented efficacy at the lowest overall cost. By offering LEDs in chip, packaged and module form, we deliver supply chain flexibility to the inventors of next generation illumination.
Philips Lumileds understands that solid state lighting is not just about energy efficiency. It is about elegant design. Reinventing form. Engineering new materials. Pioneering markets and simplifying the supply chain. It’s about a shared vision. Learn more about our comprehensive portfolio of LEDs at

About Royal Philips:
Royal Philips (NYSE: PHG, AEX: PHIA) is a diversified health and well-being company, focused on improving people’s lives through meaningful innovation in the areas of Healthcare, Consumer Lifestyle and Lighting. Headquartered in the Netherlands, Philips posted 2014 sales of EUR 21.4 billion and employs approximately 105,000 employees with sales and services in more than 100 countries. The company is a leader in cardiac care, acute care and home healthcare, energy efficient lighting solutions and new lighting applications, as well as male shaving and grooming and oral healthcare. News from Philips is located at
