Products, Materials + Tools | Feb 10, 2010

ROHM Semiconductor Presents the Industry's Thinnest High-bright RGB LEDs

ROHM Semiconductor GmbH has recently announced the development of two types of high-bright RGB LEDs: SMLV56RGB1W1, featuring a height of only 0.6mm, and the standard-type SMLW56RGB1W1, featuring a height of 1.1mm. Both units are capable of 1.8cd (white).

RGB LEDs are convenient because they can emit virtually any color, including white, while taking up very little space since the three elements are integrated into a single, compact form factor without reducing reliability. This makes them for instance the preferred choice in portable gaming devices and applications requiring high brightness and multiple colors in a small area (display blocks, LED spotlights, illumination devices, and more).

One drawback to high brightness LEDs is the small distance between the LED and target object, often due to the relatively large package height of conventional LEDs (at least 1.4mm). This often results in non-uniform light distribution or LED see-through, where the LED is visible through the object itself.

ROHM solved these issues with the SMLV56RGB1W1 in the thinnest form factor on the market. An industry-leading package height of only 0.6mm has been achieved due to a novel flat frame structure. This makes it possible to configure the LED a longer distance away from the object, enabling uniform light transmission with excellent colour blending characteristics.

Both SMLV56RGB1W1 and SMLW56RGB1W1 integrate protection Zener diodes to prevent damage due to ESD, and classification is performed based on white light emission, ensuring little variation in chromaticity for greater uniformity and consistency between the products.

Key Features:
• High luminance: 1.8cd (when emitting white light)
• Industry’s thinnest profile (t=0.6mm) ensures superior colour blending and uniformity (SMLV56RGB1W1)
• Built-in protection diodes prevent damage due to ESD
• Color sorting performed to minimize variations

Availability:
The SMLV56RGB1W1 and the standard-type SMLW56RGB1W1 are available now.

About ROHM Semiconductor:
ROHM Semiconductor - a name which stands for quality in the electronic industry with over 20,000 employees who produce a wide range of internationally marketable products, such as integrated circuits, diodes, transistors, resistors, tantal capacitors, display units, and special designs, in state-of-the-art manufacturing plants in Japan, Korea, Malaysia, Thailand, the Philippines and China. Since 2009, OKI Semiconductor is part of ROHM Semiconductor Group. ROHM in Europe serves the EMEA region ( Europe and Middle East) with a staff of 167 in our sales locations all over Europe as well as the recently created European Design Centre in Willich, Germany. For further information please contact www.rohmeurope.com
